Cu-Ti Alloy

Cu-Ti Alloy	Alloy Name Cu-Ti Alloy	Electrical Resistivity at 20°C（μΩ.Cm） -	TCR (TC in ppm/K) -	TCR (between) -	Density (g/cm³) -	Din Material Code -

Product Introduction

1. High mechanical strength and good formability (high mechanical strength and excellent formability of over 1GPa)

2. Higher conductivity than general titanium alloy

3. (*Special specifications) *High mechanical strength and excellent formability exceeding 1GPa

4. Highly conductive titanium-copper alloy. Excellent mechanical properties, and conductivity from 13% to 20%.

5. It has similar electrical conductivity, mechanical strength and formability as beryllium copper (heat treated material). However, it has better stress release characteristics. It is suitable for advanced switches, battery terminals, sockets and other electronic parts. It can be used as an alternative. Copper material.

6. Chemical composition (%): Ti: 1.5 – 3.5, Cu: Balance. (Cu + Ti ≧ 99.6)

Product Function

1. Higher conductivity than ordinary titanium-copper alloy (20% IACS)

2. * Excellent mechanical strength and formability.

(0.2% yield strength: 900MPa, MBR/t = minimum bend radius / thickness = 0)

*Thickness: 0.1mm

3. Excellent stress release characteristics (stress release ratio: 5% @ 150°C, 1000 hours)

4. Resistivity: 132-172 nΩ ? m(@20°C)

5. Thermal conductivity: 54 W/mK

6. Thermal expansion coefficient: 18.6 × 10-6 / K (20 to 300 ° C)

7. Young's coefficient: 127 GPa

8. Specific gravity: 8.70 g/cm3

9. Tensile strength: 785 – 1030 MPa

Applications

It is a copper alloy of the same performance as the beryllium copper after heat treatment. Suitable for:

Switch,

Connector,

Relay device.

Battery terminal,

Socket,

Other electronic parts,

Can be used as a substitute for beryllium copper.

NEXTECK supplies variety standards and customized world-class resistance alloys. All materials from strips, sheets, foils, wires as well as E-Beam Welding strips (EBW) are built for low value surface mount resistors, auto potentiometers, consumer electronics, tests, automatic controls and other fields.

NEXTECK originated in the metal smelting and processing and has a very long history. We belongs to the world's leading company in the production of thermo-electric alloys, resistance alloys, low resistance precision resistances and power resistances.

It is more effective to ensure product quality and customer service. Our measurements (standard temperature, mechanical and electronic) received long-term monitoring, which ensures the accuracy of the product again. The chemical and physical properties of our alloys are ensured through modern measuring and analysis systems. Among others, these include: optical emission spectrometer, surface electron microscope (SEM), EDX analyzer, elongation tester as well as length and hardness test devices.

ALLOY NAME	DIN SYMBOL	R.VALUE	CONDUCTIVITY	TCR ON PPM/K	TEMP RANGE	DENSITY	DIN CODE
ALLOY NAME	DIN SYMBOL	μΩ/Cm/20°C	S/W	TCR ON PPM/K	TEMP RANGE	g/cm3	DIN CODE
NEX^TMFCA145	FeCr21Al6	145	-	+33	20 and 100°C	7.10	-
NEX^TMFCA142	FeCr21Al4	142	-	+40 to +60	20 and 100°C	7.9	-
NEXOHM^?	NiCr20AlSi	132	0.76	Standard:±50. Special:±3. ±10°C	20 and 105°C	8	2.4872
NEX^TMNC6015	NiCr6015	111	0.9	+100 to +200	20 and 105°C	8.2	2.4867
NEX^TMNC8020	NiCr8020	108	0.93	+50 to +150	20 and 105°C	8.3	2.4869
NEX^TMNC3020	NiCr3020	104	0.96	+300 to +400	20 and 105°C	7.9	1.486
NEX^TMCM25	CuMnNi25-10	90	1.11	±10	20 and 50°C	8	-
NEXCN44^?	CuNi44	49	2.04	Standard:-80 to +40 Special:±10	20 and 105°C	8.9	2.0842
NEX^TMNC30F	NiCu30Fe	49	2.04	+400 to +600	20 and 105°C	8.9	2.436
NEXMANGAN^?	CuMn12Ni	43	2.33	Standard:±10 Special:±3	20 and 50°C	8.4	2.1362
NEX^TMCN30M	CuNi30Mn	40	2.5	+80 to +130	20 and 105°C	8.8	2.089
NEX^TMNF30	NiFe30	33	3.03	Approx +3200	0 and 100°C	8.5	-
NEX^TMCN23M	CuNi23Mn	30	3.33	Approx +180	20 and 105°C	8.9	2.0881
NEXZERAN^?	CuMn7Sn	29	3.45	Standard:±10. Special:±3	20 and 60°C	8.5	-
NEX^TMNF28	NiFe28	21	4.76	Approx +4500	20 and 100°C	8.5	-
NEX^TMCN15	CuNi15	21	4.76	Approx +300	20 and 60°C	8.9	-
NEX^TMCN10	CuNi10	15	6.67	+350 to +450	20 and 105°C	8.9	2.0811
NEX^TMCM3	CuMn3	12.5	8	+280 to +380	20 and 105°C	8.8	2.1356
NEX^TMCN6	CuNi6	10	10	+500 to +900	20 and 105°C	8.9	2.0807
NEX^TMN99.2	Ni99.2	9	11.1	+4700 to +5800	0 and 100°C	8.9	2.4066
NEX^TMN99.6	Ni99.6	8	12.5	+5300 to +6400	0 and 100°C	8.9	2.406
NEX^TMN99.4	Ni99.4Fe	8	12.5	6180	0 and 100°C	8.9	2.4062
NEX^TMN99.98	Ni99.98	7	14.3	6600	0 and 100°C	8.9	-
NEX^TMCN2	CuNi2	5	19.8	+1000 to +1600	20 and 105°C	8.9	2.0802
NEX^TMCN1	CuNi1	2.5	40	3000	20 and 105°C	8.9	-
NEX^TMCC0.3	CuCr0.3	1.92	-	3000	20 and 105°C	8.9	-
NEX^TMC99.9	Cu-ETP/(E-Cu57)	1.7	58.8	4300	0 and 100°C	8.9	2.006
NEX^TMCT3/CTF0.2	CuTi3/CuTi3.2Fe0.2	86	20	18.6	-	8.7	-
NEX^TMCF	CuFe	132~172	10~13	18	-	8.7	-
